shanghai frp research co.,ltd.is a national key frp radome development unit which can carry out independent design,development and production according to users' specific electrical performance, structure and operational condition requirements.
| product | type | diameter | working band | structure | electrical properties | other requirement |
|---|---|---|---|---|---|---|
 |
d/j.s.c.x.ka.ku/6.5 | 6.5 | l.s.c.x.ka.ku | random (or quasi-random), polygons (or quadrilateral), honeycomb or foam sandwich | unit-wave transmittance ≥ 98%, after the installation of the radome, radar feeders vswr ≤ 10% change | wind capacity :45-67m / s period of use:15-20year operating temperature: -50-60 ℃ work environment :0-100% anti-erosion: in the island, inland climate and other long-term work, the corrosion resistant to salt spray and wind erosion of sand other requirements: meeting the national military standard anti-hail capability: compliance with state regulatory requirements |
| d/jl.sc.c.x/8.6 | 8.6 | l.s.c.x | ||||
 |
d/jl.s.c.x/11.88 | 11.8 | l.s.c.x | |||
| d/js/13.1 | 13.1 | s | ||||
 |
d/jl.s/17 | 17 | l.s | |||
| d/jl.s/20 | 20 | l.s | ||||
| d/jl.s/23 | 23 | l.s | ||||
|
d/jp.l.s.x/25 | 25 | l.s | |||
| d/jl.s/28 | 28 | l.s | ||||
| d/jp.l/44 | 44 | p.l |
